Yoke, with bolts, external male thread M 6, zinc plated steel
Datasheet (PDF)
Images are for illustration purposes only and may differ from the actual product. Some images have been generated or edited, in whole or in part, using artificial intelligence systems. The technical specifications in the product description are authoritative.
In service the clevis head links the piston rod to the load through clevis and pin. The decisive figure is the piston rod thread M 6. The dimensions come to 44 x 15 x 17 mm.

Clevis head with pin and male thread, for piston rod thread M 6

FLUIDICS EQUIPMENT Original product
Net price (excl. VAT)
€18.18 €15.28
Item FL-045853
Manufacturer no. GAKA M6
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.GAKA M6
EAN4050571314538
Customs tariff number73181595
ConditionNew
Add to Wish List Add to Compare
Artikel
FL-045853
Frequently Bought Together

This clevis head links the piston rod to the load through clevis and pin. The data sheet gives the piston rod thread M 6.

Benefits

  • Fits the piston rod thread M 6.
  • Dimension GL comes to 15 mm.
  • Dimension F comes to 44 mm.
  • Dimension D comes to 17 mm.
  • Dimension B of 12 mm as per the data sheet.

Technical data

For piston rod thread AM 6
Dimension B [mm]12
Dimension C [mm]37
Dimension D [mm]17
Dimension E [mm]6
Dimension F [mm]44
Dimension G [mm]12
Dimension H [mm]6
Dimension GL [mm]15

Applications

On a cylinder with piston rod thread M 6 the clevis head makes the link to the load.

More Information
Hersteller-Nr GAKA M6
Manufacturer Fluidics equipment
EAN 4050571314538
Weight 0.020000
Zolltarifnummer 73181595
GPSR Herstellerdaten A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Artikel-Authentizität Original product
Artikelzustand New
Position sensing No
