Yoke with bolts M 12, Zinc plated steel
Datasheet (PDF)
Images are for illustration purposes only and may differ from the actual product. Some images have been generated or edited, in whole or in part, using artificial intelligence systems. The technical specifications in the product description are authoritative.
In service the clevis head links the piston rod to the load through clevis and pin. The decisive figure is the piston rod thread M 12. Dimensions 62 x 48 x 33 mm, made of zinc-plated steel.

Clevis head with pin, for piston rod thread M 12, zinc-plated steel

FLUIDICS EQUIPMENT Original product
Net price (excl. VAT)
€8.93 €7.50
Item FL-004522
Manufacturer no. GAK M12
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.GAK M12
EAN4050571314651
Customs tariff number73269098
ConditionNew
Add to Wish List Add to Compare
Artikel
FL-004522

This clevis head links the piston rod to the load through clevis and pin. The stated material is zinc-plated steel. The article is listed with the piston rod thread M 12.

Benefits

  • Fits the piston rod thread M 12.
  • Material zinc-plated steel for piston rod thread M 12.
  • Dimension F comes to 62 mm.
  • Dimension D comes to 33 mm.
  • Dimension C comes to 48 mm.

Technical data

Materialzinc-plated steel
For piston rod thread AM 12
Dimension B [mm]24
Dimension C [mm]48
Dimension D [mm]33
Dimension E [mm]12
Dimension F [mm]62
Dimension G [mm]24
Dimension H [mm]12

Applications

On a cylinder with piston rod thread M 12 the clevis head makes the link to the load.

More Information
Hersteller-Nr GAK M12
Manufacturer Fluidics equipment
EAN 4050571314651
Weight 0.145000
Zolltarifnummer 73269098
GPSR Herstellerdaten A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment
Artikel-Authentizität Original product
Artikelzustand New
Position sensing No
