In service the flexible coupling compensates an offset between piston rod and load. The decisive figure is the piston rod thread M 16. Dimensions 113.0 x 40 mm, made of zinc-plated steel.
Flexible coupling, for piston rod thread M 16, zinc-plated steel
FLUIDICS EQUIPMENT Original product
Net price (excl. VAT)
€96.21 €80.85
Item FL-050373
Manufacturer no. FK M16
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.FK M16
EAN4050571299323
Customs tariff number84129080
ConditionNew
Artikel
FL-050373
Frequently Bought Together
- This Item: €96.21 €80.85
- Swivel head, M 20x1,5, plastic €47.55 €39.96
- Bracket swivel head, M 10x1,25 €63.06 €52.99
The flexible coupling compensates an offset between piston rod and load. The data state the piston rod thread M 16. The stated material is zinc-plated steel.
Benefits
- Fits the piston rod thread M 16.
- Material zinc-plated steel for piston rod thread M 16.
- Dimension D comes to 113.0 mm.
- Dimension B comes to 40 mm.
- A radial play of 2.0 mm takes up the offset.
Technical data
| Material | zinc-plated steel |
|---|---|
| For piston rod thread A | M 16 |
| Dimension B [mm] | 40 |
| Dimension D [mm] | 113.0 |
| Width across flats SW1 [mm] | 30 |
| Width across flats SW2 [mm] | 41 |
| Radial play [mm] | 2.0 |
Applications
On a cylinder with piston rod thread M 16 the flexible coupling makes the link to the load.
| Hersteller-Nr | FK M16 |
|---|---|
| Manufacturer | Fluidics equipment |
| EAN | 4050571299323 |
| Weight | 0.650000 |
| Zolltarifnummer | 84129080 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
