Images are for illustration purposes only and may differ from the actual product. Some images have been generated or edited, in whole or in part, using artificial intelligence systems. The technical specifications in the product description are authoritative.
The vacuum filter protects vacuum pumps and blowers against ingested dust. The underlying rating is a suction rate at 0.02 bar differential pressure of 50 m³/h. Dimension port thread G 3/4", diameter 96 mm, height 93 mm.
Vacuum filter for pumps and blowers, port G 3/4", diameter 96 mm, height 93 mm
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€120.92 €101.61
Item
FL-051392
Manufacturer no.
F 34 VU
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.F 34 VU
EAN4050571292140
Customs tariff number84213925
ConditionNew
Artikel
FL-051392
Frequently Bought Together
- This Item: €120.92 €101.61
- Flat suction cup, Ø 22 mm, stroke 0.5 mm, CR (50A), black, with a support rib €4.02 €3.38
- Flat suction cups, support rib, P,series- Ø 32x2mm, Silicone (50A), transparent €9.23 €7.76
In use, the vacuum filter protects vacuum pumps and blowers against ingested dust. The data also state an overall height of 93 mm. Its rating is a suction rate at 0.02 bar differential pressure of 50 m³/h.
Benefits
- Suction rate at 0.02 bar differential pressure 50 m³/h.
- Suction rate at 0.02 bar differential pressure of 830 l/min as per the data sheet.
- Listed with Height of the complete filter 93 mm.
- Diameter of the complete filter 96 mm.
- Height of the filter element of 69 mm as per the data sheet.
Technical data
| Version | vacuum filter |
|---|---|
| Port thread | G 3/4" |
| Suction rate at 0.02 bar differential pressure [m³/h] | 50 |
| Suction rate at 0.02 bar differential pressure [l/min] | 830 |
| Height of the complete filter [mm] | 93 |
| Diameter of the complete filter [mm] | 96 |
| Height of the filter element [mm] | 69 |
| Diameter of the filter element [mm] | 64 |
| Seals | NBR |
| Filter pore size | 5 - 7 µm |
Applications
Typical use is anywhere the vacuum filter has to protect vacuum pumps and blowers against dust.
| Hersteller-Nr | F 34 VU |
|---|---|
| Manufacturer | Fluidics equipment |
| EAN | 4050571292140 |
| Weight | 0.750000 |
| Zolltarifnummer | 84213925 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Position sensing | No |
