2/2 way poppet valve, air piloted, NC, G1/2, PTFE, brass - Norgren 8218200.0000.00000
Reaches a B10 value of 500,000 cycles according to the manufacturer. Norgren 8218200.0000.00000 is a 2/2 way poppet valve with G1/2 port and rated for 0 to 16 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The Norgren 2/2 way poppet valve 8218200.0000.00000 has a G1/2 port and operates from 0 to 16 bar. The valve with PTFE seals reaches a B10 value of 500,000 cycles according to the manufacturer.
Benefits
- Operating pressure 0 to 16 bar
- Kv value 4.8 m³/h as the sizing figure for the line
- Nominal diameter 15 mm
- B10 value 500,000 cycles for maintenance planning
- Fluid temperature -10 to 180 °C with PTFE seals
- Ambient temperature -10 to 180 °C
Applications
The valve from the 82180 series is installed in lines that switch gases and liquids.
Technical data
| Manufacturer | Norgren |
|---|---|
| Manufacturer part number | 8218200.0000.00000 |
| Product type | 2/2 way poppet valve |
| Series | 82180 |
| Valve function | 2/2 |
| Normal position | Normally closed (NC) |
| Actuation | air pilot / spring return |
| Port size | G1/2 |
| Nominal diameter | 15 mm |
| Operating pressure | 0 to 16 bar |
| Kv value | 4.8 m³/h |
| Medium | gases and liquids |
| Fluid temperature | -10 to 180 °C |
| Ambient temperature | -10 to 180 °C |
| Body material | brass |
| Seal material | PTFE |
| Valve technology | poppet valve |
| B10 value | 500,000 cycles |
| Dimensions L x W x H | 80 x 180 x 65 mm |
| Certificates | DIN EN ISO 13849 |
| RoHS | compliant |
| Weight | 1.3 kg |
| Hersteller-Nr | 8218200.0000.00000 |
| Zolltarifnummer | 84818059 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Nominal size DN [mm] | 15 |
| Housing material | Brass |
| Function | 2/2 closed monostable |
| Actuation type | pneumatic |
| Certification | DIN EN ISO 13849 |
| Betriebsdruck max [bar] | 16 |
| Pneumatic connection | G1/2 |
