Keeps the working pressure stable and thereby lowers air consumption. The Excelon Plus general purpose regulator Norgren R82G-3GK-RFN is manufactured in Mexico and is designed for port G3/8.
Excelon Plus general purpose regulator, G3/8, 0.3-4 bar - Norgren R82G-3GK-RFN
NORGREN
Original product
Net price (excl. VAT)
€46.21
Item
NRG-R82G-3GK-RFN
Manufacturer no.
R82G-3GK-RFN
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.R82G-3GK-RFN
Customs tariff number84811099
ConditionNew
Artikel
NRG-R82G-3GK-RFN
Frequently Bought Together
Pressure regulators keep the working pressure constant even when the line pressure varies. The Excelon Plus general purpose regulator Norgren R82G-3GK-RFN is manufactured in Mexico and seals with nitrile rubber (nbr).
Benefits
- Reduced weight and size
- Flexible modular system
- Push to lock adjusting knob with built in tamper resistant feature
- Port size G3/8
- Outlet pressure adjustable from 0.3 to 4 bar
- Flow 31 dm³/s
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren R82G-3GK-RFN |
| Series | R82G |
| Product line | Excelon Plus |
| Excelon Plus size | 82 Series |
| Regulator type | General purpose |
| Relieving function | Relieving |
| Adjustment | Knob |
| Adjusting knob | Acetal |
| Port size | G3/8 |
| Gauge port | Rc1/8 |
| Maximum inlet pressure | 20 bar |
| Adjustable outlet pressure | 0.3 to 4 bar |
| Flow | 31 dm³/s |
| Medium | Compressed air |
| Temperature range | -20 to 65 °C |
| Body material | Aluminium alloy |
| Spring bonnet | Acetal |
| Seal material | Nitrile rubber (NBR) |
| Height | 47 mm |
| Width | 56 mm |
| Length | 115 mm |
| Weight | 0.23 kg |
| Country of origin | Mexico |
| RoHS | Compliant |
| REACH | SVHC substance not present |
| WEEE | Non-WEEE |
Applications
Typical installations are production lines, test benches and machines with several pressure levels.
Standards and conformity
The version is RoHS compliant, no SVHC substances are present under REACH. The product does not fall under the WEEE directive.
| Weight | 0.300000 |
|---|---|
| Manufacturer | Norgren |
| Hersteller-Nr | R82G-3GK-RFN |
| Zolltarifnummer | 84811099 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
