Torque Wrench Drive Unit, 11.484 Nm - Enerpac W8000X

The W8000X drive unit delivers up to 11,484 Nm and, together with the W-Series interchangeable cassettes, forms a complete hydraulic torque wrench. A strong strength-to-size ratio reaches difficult bolting locations without sacrificing endurance.

Benefits

• Up to 11,484 Nm of torque at +/-3% accuracy across the full stroke
• 30° rotation angle and rapid return stroke for fast operation
• Tool-free fast release for quick cassette change-over
• Handles mount on both sides for extra maneuverability
• Compatible with standard, X-Edition and UltraSlim W-Series cassettes

Technical data

• Type: Torque wrench drive unit
• Max. torque: 11,484 Nm
• Torque accuracy: +/-3%
• Rotation angle: 30°
• Weight: 3 kg
• Series: W-Series (X-Edition)

Applications

For controlled tightening and loosening of large hexagon bolted joints on flanges, for example in plant construction and the oil and gas industry.

Standards

• CE and ATEX declared
• Factory calibration with certificate
