Square Drive Torque Wrench, 8338 Nm, 1 1/2 in. - Enerpac S6000X

The S6000X delivers up to 8338 Nm of torque through a 1 1/2 in. square drive, covering large bolting joints in plant construction and power generation. Constant torque output stays accurate to within +/- 3 % across the full stroke.

Benefits

• Compact uni-body construction gives a small head radius without sacrificing endurance
• 35 degree rotation angle and rapid return stroke for fast operation
• 360 degree click-on reaction arm with quick-release lever, usable even with gloves
• Push-button square drive release for quickly reversing the operating direction
• CE and ATEX declared, shipped complete with a calibration certificate

Technical data

• Torque: 8338 Nm
• Square drive: 1 1/2 in.
• Torque accuracy: +/- 3 %% across the full stroke
• Operating stroke: 35 degree drive angle
• Operating pressure: 700 bar
• Weight: 9.2 kg
• Series: S

Applications

For heavy bolting in industrial, power generation and oil and gas work. Allow about 250 percent of the tightening torque to loosen.
