Telescopic Cylinder, 309 kN, 600 mm Stroke - Enerpac RT3323

The RT3323 lifts loads with 309 kN of force through a multi-stage 600 mm stroke, reaching high lift heights from a compact 476 mm collapsed height. Nitrocarburized surface treatment inside and out provides strong corrosion protection.

Benefits

• Multi-stage telescopic stroke for high lift from a low collapsed height
• Double or triple wear bearings support the lifting stages
• Tilting saddles with up to 5 degrees of tilt for secure load contact
• Certified lifting eyes for safe handling and positioning
• CR400 coupler for compatibility with standard products
• Steel cylinder base for maximum stability

Technical data

• Capacity: 309 kN
• Stroke: 600 mm
• Collapsed height: 476 mm
• Extended height: 1076 mm
• Outside diameter: 250 mm
• Permissible side load: 3 % of rated capacity
• Operating pressure: 700 bar
• Weight: 124 kg
• Series: RT

Standards

• Designed to ASME B30.1-2015 and EN1494
