Torque Wrench Drive Unit, 4176 Nm - Enerpac RSL3000

The RSL3000 RSL-series hydraulic drive unit delivers up to 4176 Nm of torque for heavy-duty bolting in energy, oil and gas applications. Constant torque output stays accurate to within +/- 3 percent across the full stroke.

Benefits

• Constant torque with +/- 3 % accuracy for repeatable bolting results
• Enclosed design covers all moving parts and minimizes pinch points
• Robust alloy steel build with only three moving parts for reduced maintenance
• 30 - 35 degree stroke boosts productivity and avoids tool lock-on
• Interchangeable cassette design with a wide range of hexagon sizes
• Reaction arm with Dialock for fast, tool-free adjustment
• Fits the RLP hexagon cassette or the RSQ square drive cassette

Technical data

• Torque: 4176 Nm
• Torque accuracy: +/- 3 % across full stroke
• Operating stroke: 30 - 35 degree drive angle
• Operating pressure: 700 bar
• Height: 159 mm
• Weight: 2.5 kg
• Series: RSL

Applications

For bolting work across industrial, power generation and oil and gas applications. Allow about 250 percent of the tightening torque to loosen. Operate with Enerpac THQ700 twin hoses to maintain the integrity of the hydraulic system.
