Hexagon Cassette, for RSL19000, 4 1/8 in. / 105 mm AF - Enerpac RLP19402

The hexagon cassette in the 4 1/8 in. / 105 mm across-flats size equips the RSL19000 hydraulic drive unit for bolting at exactly this hex size. Because one drive unit powers the whole cassette set, purchase and set-up effort drop noticeably.

Benefits

• Interchangeable cassette system: one drive unit covers many sizes
• Constant torque within +/- 3 % across the full stroke for an even preload
• Made from hardened steel and fixed to the RSL19000 drive unit with four socket bolts

Technical data

• Across-flats size: 4 1/8 in. / 105 mm
• Matching drive unit: RSL19000
• Torque accuracy: +/- 3 % across full stroke
• Length: 344.7 mm
• Height: 261.1 mm
• Width: 69.9 mm
• Weight: 11.5 kg
• Series: RLP

Applications

Used on flange, foundation and large-diameter connections that are tightened or released at the 4 1/8 in. / 105 mm across-flats size with the RSL19000 drive unit.
