Hexagon Cassette, Imperial, 2 11/16 in. AF, for RSL11000 - Enerpac RLP11211

At a 2 11/16 in. across-flats size, this interchangeable cassette brings the hydraulic torque of the RSL11000 drive unit to the joint. The modular design allows a quick change to other sizes without swapping the complete tool.

Benefits

• Interchangeable cassette system: one drive unit covers many sizes
• Constant torque within +/- 3 % across the full stroke for an even preload
• Made from hardened steel and fixed to the RSL11000 drive unit with four socket bolts

Technical data

• Across-flats size: 2 11/16 in.
• Matching drive unit: RSL11000
• Torque accuracy: +/- 3 % across full stroke
• Length: 284.5 mm
• Height: 209.0 mm
• Width: 63.5 mm
• Weight: 6.7 kg
• Series: RLP

Applications

Used on flange, foundation and large-diameter connections that are tightened or released at the 2 11/16 in. across-flats size with the RSL11000 drive unit.
