General Purpose Hydraulic Cylinder, 45 kN, 127 mm Stroke - Enerpac RC55

The compact RC55 delivers 45 kN of force with 127 mm of stroke and suits versatile lifting, pushing and clamping tasks at a low weight of 1.9 kg.

Benefits

• TRIO bearing system with up to four wear bands that reduces bearing load and extends service life
• Hybrid spring-return system for faster retraction and higher productivity
• High-performance polyethylene seals for long service intervals
• Nickel-plated high-strength steel plunger for corrosion protection and sideload resistance
• Dimensionally identical to prior RC-Series cylinders, so fully compatible with existing systems

Technical data

• Force: 45 kN
• Stroke: 127 mm
• Action: single-acting, spring return
• Operating pressure: 700 bar
• Weight: 1.9 kg
• Series: RC

Applications

For general lifting, pushing and clamping work in maintenance, assembly and production. Collar and base threads allow easy mounting in both vertical and horizontal orientation.
