RARH3010, 359 kN Capacity, 250 mm Stroke, Double-Acting, Aluminum Hollow Plunger Hydraulic Cylinder
359 kN Capacity, 250 mm Stroke, Double-Acting, Aluminum Hollow Plunger Hydraulic Cylinder - Enerpac RARH3010
ENERPAC
Original product
Net price (excl. VAT)
€4,773.55
€4,011.39
excl. Shipping Cost
Available
Fast shipping
Item
ENP-RARH3010
Manufacturer no.
RARH3010
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.RARH3010
Country of originUnited States
ConditionNeu
Artikel
ENP-RARH3010
Frequently Bought Together
-
This Item:
€4,773.55 €4,011.39excl. Shipping Cost
-
45 kN Capacity, 232 mm Stroke, General Purpose Hydraulic Cylinder - Enerpac RC59
€682.50 €573.53excl. Shipping Cost
-
1497 kN Capacity, 250 mm Stroke, Single-Acting, High Tonnage Hydraulic Cylinder - Enerpac HCG15010
€3,654.49 €3,071.00excl. Shipping Cost
Model: RARH3010 |ECCN: EAR99 | Harmonization: 8412210075
Series: RARH |Product Line: Industrial Tools
Series: RARH |Product Line: Industrial Tools
- Lighter and shorter collapsed height than equivalent RACH single-acting models
- Double-acting for rapid retraction, regardless of hose lengths or system losses
- Built-in safety valve prevents accidental overpressurization
- Hollow plunger design allows for both pull and push forces
- Composite bearings increase cylinder life and side load resistance
- Hard coat finish on all surfaces resists damage and extends cylinder life
- Handles included on all models
- Floating center tube increases seal life
- Steel baseplate and saddle for protection against load-induced damage
- Integral stop ring prevents plunger over-travel and is capable of withstanding the full cylinder capacity
- CR400 coupler and dust cap included on all models
- All cylinders meet ASME B-30.1 standards
Dimension imperial
Collapsed Height A (in)
16.1
Extended Height B (in)
25.94
Outside Diameter D (in)
5.31
Cylinder Bore Diameter E (in)
3.74
Plunger Diameter F (in)
2.95
Base to Advance Port H (in)
0.86
Saddle Diameter J1 (in)
2.49
Saddle Protrusion from Plunger K (in)
0.38
Plunger Internal Thread O (in)
1 13/16"-16 UN
Plunger Thread Length P (in)
0.91
Base Mounting Holes Bolt Circle U (in)
4.33
Base Mounting Holes Thread V
M6
Center Hole Diameter Y (in)
1.34
Base Mounting Holes Thread Depth Z (in)
0.47
Dimension metric
Collapsed Height A (mm)
409
Extended Height B (mm)
659
Outside Diameter D (mm)
135
Cylinder Bore Diameter E (mm)
95
Plunger Diameter F (mm)
75
Base to Advance Port H (mm)
22
Saddle Diameter J (mm)
63
Plunger Internal Thread O (in)
1 13/16"-16 UN
Plunger Thread Length P (mm)
23
Base Mounting Holes Bolt Circle U (mm)
110
Base Mounting Holes Thread V
M6
Center Hole Diameter Y (mm)
34
Base Mounting Holes Thread Depth Z (mm)
12
| Hersteller-Nr | RARH3010 |
|---|---|
| Manufacturer | Enerpac |
| Country of Manufacture | United States |
| Weight | 14.900000 |
| Hinweis | Industriewerkzeuge |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikel-Authentizität | Originalprodukt |
| Artikelzustand | Neu |
