Aluminum Hydraulic Cylinder, 1002 kN, 100 mm Stroke - Enerpac RAC1004

The RAC1004 pushes and lifts loads at 1002 kN over a 100 mm stroke and weighs 19.6 kg, about half of a comparable steel cylinder. A high-strength return spring retracts the plunger quickly after the job.

Benefits

• Aluminum construction at roughly half the weight for easier transport and positioning
• Hard coat finish resists damage and extends cylinder life
• Composite bearings prevent metal-to-metal contact and add side-load resistance of up to 10%
• Integral stop ring prevents plunger over-travel
• High-strength return spring for rapid cylinder retraction
• Steel baseplate, saddle and handles as standard

Technical data

• Capacity: 1002 kN
• Stroke: 100 mm
• Type: single-acting, spring return
• Operating pressure: 700 bar
• Coupler: CR400 with dust cap
• Weight: 19.6 kg
• Series: RAC

Standards

• ASME B30.1
