Pneumatic POW'R-RISER Lifting Jack, 889 kN, 406 mm Stroke - Enerpac PRASA10016L

The PRASA10016L lifts and positions heavy loads with 889 kN capacity over a 406 mm stroke. The double-acting cylinder extends powerfully and retracts under control, while the fully enclosed frame protects all fittings and hoses.

Benefits

• Double-acting cylinder for controlled lifting and lowering of heavy loads
• 102 mm ground clearance for transport over rail and rough terrain
• Three-position handle for easy tilt-back and transport
• Fully enclosed 610 mm wide frame with no exposed fittings or hoses
• Driven by air or electric pumps, even for the most demanding requirements
• SUP-R-STACK extension sets for lifting at any height without blocking the cylinder

Technical data

• Capacity: 889 kN
• Stroke: 406 mm
• Action: double-acting
• Drive: pneumatic
• Ground clearance: 102 mm
• Frame width: 610 mm
• Weight: 231 kg
• Series: POW'R-RISER (PR)

Applications

For heavy-load lifting in rail, bridge and heavy-industry work. The SUP-R-STACK extensions increase the usable lift height without blocking.

Standards

• ASME/ANSI B30.1
• CE
