Nut Splitter Power Head, Hexagon up to 100 mm - Enerpac NSPH3

The NSPH3 power head splits hexagon nuts up to 100 mm and lets the cutting depth be preset via a blade positioning scale, so the bolt thread stays undamaged as the nut is cut. The unit is single-acting, spring return.

Benefits

• Blade positioning scale protects the bolt thread during the cut
• Adjustable cutting depth for UN and metric threads
• Interchangeable power heads with cutting blade
• Designed to fit standard BS/ANSI flanges

Technical data

• Hexagon size: up to 100 mm
• Action: single-acting, spring return
• Coupler: CR400 female half coupler as standard
• Max. hardness to split: ASTM A194 Gr 2H
• Weight: 22 kg
• Series: NSPH

Applications

For bolted flange joints with UN or metric threads. Not to be used on square nuts or stainless steel.

In the box

• Spare chisel
• Spare set screw
• Locking wrench for the chisel

Standards

• CE and ATEX certified
