Low Height Lock Nut Cylinder, 606 kN, 50 mm Stroke - Enerpac LPL602

This low-height cylinder pushes with 606 kN over a 50 mm stroke and is built for heavy-duty work where clearance is restricted. The lock nut takes over mechanical load holding, keeping the position secure over extended periods.

Benefits

• Lock nut provides mechanical load holding for a safe work environment
• Integrated tilt saddle allows up to 5 degrees of misalignment
• Extreme low-height for use in confined areas
• 10 % side-load resistance of maximum capacity
• Overflow port as stroke limiter prevents plunger blow-out

Technical data

• Capacity: 606 kN
• Stroke: 50 mm
• Collapsed height: 125 mm
• Outside diameter: 140 mm
• Action: single-acting, gravity-return
• Operating pressure: 700 bar
• Saddle tilt: up to 5 degrees
• Weight: 15 kg
• Series: LPL
