High Tonnage Hydraulic Cylinder, 1002 kN, 100 mm Stroke - Enerpac HCL1004

The HCL1004 lifts and supports heavy loads with 1002 kN of force over a stroke of 100 mm and then locks the position purely mechanically. The threaded lock nut takes over holding, so the load stays securely fixed even if hydraulic pressure drops.

Benefits

• Lock nut provides positive mechanical load holding, independent of hydraulic pressure
• Low-friction locking rings spin easily, saving time when securing the load
• Withstands up to 10% side load over 90% of the stroke
• Hardened surface resists side-loading and cyclic wear
• Overflow port limits stroke and prevents plunger blow-out
• Weather-protected design for indoor and outdoor use
• Replaceable bearings enclose the plunger for stability throughout the stroke

Technical data

• Capacity: 1002 kN
• Stroke: 100 mm
• Action: single-acting, with lock nut
• Operating pressure: 700 bar
• Weight: 44 kg
• Series: HCL
