High Tonnage Hydraulic Cylinder, 550 kN, 100 mm Stroke - Enerpac HCG504

The HCG504 provides 550 kN of force at 100 mm stroke as a single-acting high-tonnage cylinder built for continuous duty. As a single-acting high-tonnage cylinder with a hardened plunger surface, it is built for cyclic duty in plant and machinery work.

Benefits

• Hardened plunger surface resists side loading and cyclic wear
• 10 % side-load resistance across the full cylinder capacity
• Stop-ring prevents plunger blow-out at the end of the stroke
• Weather protected for use indoors and outdoors
• Upper and lower replaceable bearings guide the plunger throughout the stroke
• Certified lifting eyes and base mounting holes for safe handling and installation

Technical data

• Force: 550 kN
• Stroke: 100 mm
• Action: single-acting
• Operating pressure: 700 bar
• Weight: 20 kg
• Series: HCG

Applications

Suited to lifting, pressing and positioning tasks with high force demand in structural steel and plant work, machine installation and structural load transfer. Operate with 700 bar hydraulic power units and matching high-pressure hoses.
