Hydraulic Wire and Cable Cutter, 550 kN, Material Diameter 90 mm - Enerpac EWCH90

The EWCH90 cuts cable and wire rope with 550 kN of cutting force at material diameters up to 90 mm. Drive from an external hydraulic pump keeps the tool cool and supports demanding cutting work with high duty cycles.

Benefits

• High cutting force and long duty cycles from an external hydraulic pump
• Controlled, low-spark cut instead of torching, grinding or sawing
• Low vibration, helping prevent Hand Arm Vibration Syndrome (HAVS)
• Opening cutting head for easy positioning of the material
• Double-acting cylinder with advance and retract buttons reduces jamming
• Guillotine-style blades stay effective under the toughest conditions

Technical data

• Cutting force: 550 kN
• Material diameter: up to 90 mm
• Cylinder: double-acting
• Weight: 53 kg
• Series: EWCH

Applications

For demanding, high-volume cutting in production facilities. Designed for ZE6410X-Series electric pumps; pump and hose are sold separately.
