Ultra Flat Hydraulic Cylinder with Stop Ring, 550 kN, 6 mm Stroke - Enerpac CULP50

The CULP50 is an ultra-flat hydraulic cylinder delivering 550 kN of force over a 6 mm stroke, working in very tight spaces thanks to a collapsed height of only 44.5 mm. The stop ring limits maximum stroke and protects the cylinder from over-extension.

Benefits

• Extremely low collapsed height of 44.5 mm for confined installations
• Stop ring limits the stroke and prevents over-extension of the cylinder
• Handles up to 4 % side load at full rated capacity
• Nitrocarburized surface for enhanced corrosion protection in harsh conditions
• Coupler AR630 with dust cap, connect to the pump with an HB7206 hose

Technical data

• Capacity: 550 kN
• Stroke: 6 mm
• Collapsed height: 44.5 mm
• Extended height: 50.5 mm
• Outside diameter: 140 mm
• Bore diameter: 100 mm
• Operating pressure: 700 bar
• Weight: 5.4 kg
• Series: CULP

Applications

Suited to lifting and positioning tasks in confined spaces where conventional cylinders will not fit.
