Ultra-flat hydraulic cylinder with 198 kN capacity and 6 mm stroke at just 32 mm collapsed height. The stop ring limits the stroke and protects the cylinder in tight spaces.
Ultra Flat Hydraulic Cylinder with Stop Ring, 198 kN, 6 mm Stroke - Enerpac CULP20
ENERPAC Original product
Net price (excl. VAT)
€622.61 €523.20
Item ENP-CULP20
Manufacturer no. CULP20
Personal expert advice
Brand new Specialist dealer since 2009 Original product Worldwide shipping
Product data
Manufacturer no.CULP20
Country of originUnited States
ConditionNew
Artikel
ENP-CULP20
Frequently Bought Together
- This Item: €622.61 €523.20
- Cartridge Swing Clamp 4.9 kN single-acting, right-turning - Enerpac SCRS52 €916.42 €770.10
- Block Cylinder double-acting 11 kN 16 mm Stroke - Enerpac BMD10162 €467.31 €392.70
The CULP20 is an ultra-flat hydraulic cylinder delivering 198 kN of force over a 6 mm stroke, working in very tight spaces thanks to a collapsed height of only 32 mm. The stop ring limits maximum stroke and protects the cylinder from over-extension.
Benefits
- Extremely low collapsed height of 32 mm for confined installations
- Stop ring limits the stroke and prevents over-extension of the cylinder
- Handles up to 4 % side load at full rated capacity
- Nitrocarburized surface for enhanced corrosion protection in harsh conditions
- Coupler AR630 with dust cap, connect to the pump with an HB7206 hose
Technical data
- Capacity: 198 kN
- Stroke: 6 mm
- Collapsed height: 32 mm
- Extended height: 38 mm
- Outside diameter: 90 mm
- Bore diameter: 60 mm
- Operating pressure: 700 bar
- Weight: 1.7 kg
- Series: CULP
Applications
Suited to lifting and positioning tasks in confined spaces where conventional cylinders will not fit.
| Hersteller-Nr | CULP20 |
|---|---|
| Manufacturer | Enerpac |
| Country of Manufacture | United States |
| Weight | 1.700000 |
| Hinweis | Industriewerkzeuge |
| GPSR Herstellerdaten | Enerpac GmbH, Willstätterstraße 13, DE-40549 Düsseldorf, www.enerpac.com |
| Artikel-Authentizität | Original product |
| Artikelzustand | New |
| Series | CULP |
| Kapazität, kN | 100-250 kN |
| Position sensing | No |
