Electrical multi-pole connection for EB 80 valve island, 25-pin, 12 and 24 V DC, type 02282E025 - Riegler 150955

Name: Electrical multi-pole connection for EB 80 valve island, 25-pin, 12 and 24 V DC, type 02282E025 - Riegler 150955
Brand: Riegler
SKU: RGL-150955
Price: 101.96 EUR
Availability: InStock

Riegler ✓ Original product Brand new Made in Italy

This 25-pin multi-pole connection powers the EB 80 valve island and transmits the control signals to the solenoid valves. It runs on 12 or 24 V DC and controls up to 21 valves.

Net

€101.96

excl. VAT

Item RGL-150955

Manufacturer no. 02282E025

Question about this item

Datasheet (PDF) User manual 4 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

Parallel wiring with full diagnostics: module 02282E025 is the electrical connection of an EB 80 island in multi-pole design with a one-piece metal housing. It works from 10.8 V DC and tolerates overvoltages up to 31.2 V DC. Voltages above 32 V DC will damage the system irreparably.

Advantages

25-pin multi-pole connection, 12 and 24 V DC
Operating voltage 10.8 V DC to 31.2 V DC
Up to 21 controllable valves
Diagnostic functions via electronics in all modules
Protection rating IP 65

Applications

Compact valve islands in special-purpose machines and production lines controlled via multi-pole or fieldbus.

Technical data

Type no.	02282E025
Seal material	NBR
Duty cycle	100 %
Version	25-pin
Supply voltage range	12 -10 % to 24 +30 % V DC
Operating voltage	10.8 to 31.2 V DC
Maximum admissible voltage	32 V DC
Ambient temperature	-10 to 50 °C
Housing	painted aluminium
Module type	E
Module description	multi-pole electrical connection
Protection	system: overload, output: short-circuit
Diagnostics	FAULT (red) and OUT on electr. connection-E, LED on valve
Diagnostic signals	short circuit, no control signal, invalid operating voltage
Switching polarity	configurable PNP or NPN
Power consumption without valve control	0.1 W for module electr. conn.-E + 0.25 W per Base-B
Solenoid pilot power on start-up (speed up)	3 W for 15 ms
Maximum number of controllable solenoid valves	21, depending on number of solenoid pilots and type of base
Maximum number of simultaneous solenoid controls on activation	24 V DC: 21 / 12 V DC: depending on voltage drop
Maximum admissible current, continuous	6 A
Maximum admissible current, instantaneous	9 A
Maximum number of solenoid controls	21
Maximum current at 24 V DC	3 A
Maximum current at 12 V DC	6 A
Power input	max. 3.15 W
Protection rating	IP 65
Series	EB 80
Weight	0.204 kg
Manufacturer	Riegler
Hersteller-Nr	02282E025
EAN	4047322814317
Zolltarifnummer	84818099
GPSR Herstellerdaten	Riegler & Co. KG, Schützenstraße 27, DE-72574 Bad Urach, www.riegler.de
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Italy
Ausführung	25-polig
Material	Aluminium, painted
Housing material	Aluminium, painted
Temperaturbereich	-10-50 °C
Temperature (max.)	50
