Electrical fieldbus connection for EB 80 valve island, CC-Link IE Field Basic, 12 and 24 V DC, type 02282E0CC - Riegler 150965

Name: Electrical fieldbus connection for EB 80 valve island, CC-Link IE Field Basic, 12 and 24 V DC, type 02282E0CC - Riegler 150965
Brand: Riegler
SKU: RGL-150965
Price: 478.72 EUR
Availability: InStock

Riegler ✓ Original product Brand new Made in Italy

This fieldbus connection links the EB 80 valve island to the controller via CC-Link IE Field Basic, powers it and handles diagnostics. Up to 128 solenoid controls are possible.

Net

€478.72

excl. VAT

Item RGL-150965

Manufacturer no. 02282E0CC

Question about this item

Datasheet (PDF) User manual 6 documents, all under Downloads

Specialist dealer since 2009
Invoice payment for regular customers
Worldwide shipping
Technical questions clarified with the manufacturer

Description

One bus line instead of many wires: module 02282E0CC is the electrical connection of an EB 80 island for CC-Link IE Field Basic. The system works with 12 and 24 V DC, from 10.8 V DC up to 31.2 V DC. Voltages above 32 V DC will damage the system irreparably.

Advantages

Fieldbus: 100 Mbit/s, number of occupied stations: from 1 to 4
Up to 128 solenoid controls
Up to 128 digital input signals and 16 analogue input signals
Diagnostics: CC-Link IE Field Basic: LED+SW info, outp.: LED+state bytes
Operating voltage 10.8 V DC to 31.2 V DC
Protection rating IP 65

Applications

Valve islands for assembly, handling and packaging machines that are built modularly and may be extended later.

Technical data

Type no.	02282E0CC
Seal material	NBR
Duty cycle	100 %
Version	CC-Link IE Field Basic
Supply voltage range	12 -10 % to 24 +30 % V DC
Operating voltage	10.8 to 31.2 V DC
Maximum admissible voltage	32 V DC
Ambient temperature	-10 to 50 °C
Housing	technopolymer / painted aluminium
Module type	E
Module description	electrical connection with fieldbus
Protection	module: overload, polarity inversion, output: overload, SC
Diagnostics	CC-Link IE Field Basic: LED+SW info, outp.: LED+state bytes
Diagnostic signals	SC, coil fail., UV/OV, mod. com., switch state, dev. config.
Power consumption without valve control	4 W for module electr. conn.-E + 0.25 W per Base-B
Solenoid pilot power on start-up (speed up)	3 W for 15 ms
Maximum number of simultaneous solenoid controls on activation	38 (greater number possible with intermediate module - M)
Fieldbus	100 Mbit/s, number of occupied stations: from 1 to 4
Maximum number of solenoid controls	128
Maximum admissible current for valve supply, continuous	4 A
Maximum admissible current for valve supply, instantaneous	6 A
Maximum admissible current for bus/signal supply, continuous	4 A
Maximum admissible current for bus/signal supply, instantaneous	6 A
Maximum number of digital input signals	128
Maximum number of digital output signals	128
Maximum number of analogue input signals	16
Maximum number of analogue output signals	16
Power input	max. 3.15 W
Protection rating	IP 65
Series	EB 80
Weight	0.35 kg
Manufacturer	Riegler
Hersteller-Nr	02282E0CC
EAN	4047322814416
Zolltarifnummer	84818099
GPSR Herstellerdaten	Riegler & Co. KG, Schützenstraße 27, DE-72574 Bad Urach, www.riegler.de
Artikelzustand	New
Artikel-Authentizität	Original product
Country of Manufacture	Italy
Ausführung	CC-Link IE Field Basic
Material	Technopolymer / aluminium, painted
Housing material	Technopolymer / aluminium, painted
Temperaturbereich	-10-50 °C
Temperature (max.)	50
