Cantilever axis ELCC-TB-KF-90-200-0H-P0-CR - Festo 8082399
Net
excl. VAT
€3,105.20
Item
FES-8082399
Manufacturer no.
ELCC-TB-KF-90-200-0H-P0-CR
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Technical data
| Effective diameter of drive pinion | 50.93 mm |
|---|---|
| Working stroke | 200 mm |
| Size | 90 |
| Stroke reserve | 0 mm |
| Toothed-belt pitch | 5 mm |
| Mounting position | Any |
| Guide | Recirculating ball bearing guide |
| Design | Electromechanical cantilever axis |
| Max. acceleration | 30 m/s² |
| Max. speed | 5 m/s |
| Repetition accuracy | ±0.05 mm |
| Corrosion resistance class CRC | 0 - No corrosion stress |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Degree of protection | IP20 |
| Ambient temperature | -10 ... 60 °C |
| 2nd moment of area Iy | 2667900 mm⁴ |
| 2nd moment of area Iz | 2049490 mm⁴ |
| Max. drive torque | 33 Nm |
| Max. force Fy | 13957 N |
| Max. force Fz | 13523 N |
| Max. moment Mx | 167 Nm |
| Max. moment My | 1300 Nm |
| Max. moment Mz | 1233 Nm |
| Max. feed force Fx | 1200 N |
| Mass moment of inertia JH per metre of stroke | 62.9 kgcm² |
| Mass moment of inertia JL per kg of working load | 6.5 kgcm² |
| Mass moment of inertia JO | 55.2 kgcm² |
| Feed constant | 160 mm/U |
| Reference service life | 5000 km |
| Lubrication interval dependent on operating distance | 1000 km |
| Moving mass for 0 mm stroke | 5487 g |
| Additional moving mass per 10 mm stroke | 97 g |
| Basic weight for 0 mm stroke | 14787 g |
| Additional weight per 10 mm stroke | 97 g |
| Material end cap | Anodised wrought aluminium alloy |
| Material profile | Anodised wrought aluminium alloy |
| Note on materials | RoHS compliant |
| Material drive head | Anodised wrought aluminium alloy |
| Material guide rail | Rolled steel, Corrotect coated |
| Material housing | High-alloy stainless steel |
| Material slide | Anodised cast aluminium |
| Material toothed belt clamping piece | Anodised wrought aluminium alloy |
| Material toothed belt | Polychloroprene with glass filament and nylon coating |
| Manufacturer | Festo |
| Hersteller-Nr | ELCC-TB-KF-90-200-0H-P0-CR |
| EAN | 4052568447915 |
| Zolltarifnummer | 84799070 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
