The adjustable elbow coupling sets a tube socket at a right angle to the line and can be turned freely to the required direction. The underlying rating is a working pressure of 315 bar. 6 L in stainless steel 1.4571.
Adjustable elbow coupling, tube 6 L, stainless steel 1.4571, light series
FLUIDICS EQUIPMENT
Original product
Net price (excl. VAT)
€52.34
Item
FL-003756
Manufacturer no.
EVW 6 L ES
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.EVW 6 L ES
EAN4050571289140
Customs tariff number73071990
ConditionNew
Artikel
FL-003756
Frequently Bought Together
-
This Item:
€52.34
-
Adjustable elbow coupling, tube 18 L, stainless steel 1.4571 without nut
€139.62
-
Adjustable elbow coupling, tube 28 L, stainless steel 1.4571
€251.29
Total price
In use, the adjustable elbow coupling sets a tube socket at a right angle to the line and can be turned freely to the required direction. The data also state a temperature range of -60 to +400 °C. This version comes with tube outside diameter 6 L.
Benefits
- After screwing in, the outlet can be turned to any direction and is then locked in place.
- The 6 L tube socket takes the union nut and the cutting ring of the light series.
- The working pressure of 315 bar applies to the fully assembled coupling.
- The temperature range covers -60 to +400 °C.
- The version in stainless steel 1.4571 sets the corrosion protection and the temperature limit of the joint.
Technical data
| Material | stainless steel 1.4571 |
|---|---|
| Series | light series |
| Tube socket diameter | 6 L |
| Tube diameter (outside) | 6 L (M12x1.5) |
| Working pressure [bar] | 315 |
| Temperature range [°C] | -60 to +400 |
Applications
On manifolds and distributors it joins tube 6 L at a right angle and 315 bar.
| Weight | 0.040000 |
|---|---|
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | EVW 6 L ES |
| EAN | 4050571289140 |
| Zolltarifnummer | 73071990 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Material | 1.4571 |
| Rohrdurchmesser (außen) | 6 L (M12x1,5) |
| Rohrstutzendurchmesser [mm] | 6 L |
| Series | leichte Baureihe |
| Temperaturbereich | -60-400 °C |
