Adjustable cutting ring fitting, thread G 1/4", tube stud 10 L, stainless steel 1.4571

This adjustable cutting ring fitting is designed for the male thread G 1/4" and a tube stud 10 L. The part clamps the cutting ring onto the tube and seals metal to metal. The operating pressure reaches up to 315 bar.

Benefits

• With tube stud 10 L the size is fixed, so no reworking of the line is required
• The operating pressure up to 315 bar is released for this size
• The temperature range from -20 °C to +200 °C covers cold installation and warm machine surroundings
• The material stainless steel 1.4571 stays resistant without additional coating in the range from -20 °C to +200 °C
• The light series with the code L follows the dimension series to ISO 8434-1

Technical data

Applications

Pipework on presses and pumps, repair of existing tube fittings, test benches and power unit construction, hydraulic lines in machine and plant engineering.

Standards and conformity

The tube fitting follows the design of cutting ring tube fittings to ISO 8434-1, formerly DIN 2353.
