Electric parallel gripper size 20, stroke per jaw 13 mm EHPS-20-A - Festo 8070831

Festo ✓ Original product Brand new

With 218 N total gripping force, the parallel gripper EHPS-20-A grips electrically without compressed air. 13 mm stroke per jaw, repetition accuracy 0.01 mm, plain-bearing guide. Supplied with 24 V DC, degree of protection IP40. Position detection with proximity switches.

Net
€1,391.29
excl. VAT
Item FES-8070831
Manufacturer no. EHPS-20-A
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The size 20 parallel gripper EHPS-20-A delivers 218 N total gripping force. An electric motor moves both jaws in parallel. Version EHPS-20-A: plain-bearing guide, rack and pinion.

Benefits

  • 218 N total gripping force
  • Repetition accuracy 0.01 mm, replacement accuracy 0.2 mm
  • 13 mm stroke per jaw, with max. 150 g per external gripper finger
  • Cycle frequency up to 0.7 Hz, current consumption max. 2000 mA
  • Corrosion resistance class CRC 1, ambient temperature 5 to 60 °C

Applications

The EHPS-20-A suits handling tasks without a compressed air supply and applications where the controller sets gripping position and gripping force. Gripper fingers are mounted on the jaws, each external finger may weigh up to 150 g. Position detection with proximity switches. Shipping weight 0.75 kg.

Technical data

Size20
Stroke per gripper jaw13 mm
Max. replacement accuracy0.2 mm
Max. angular gripper jaw backlash ax, ay0.3°
Max. gripper jaw backlash Sz0.05 mm
Rotational symmetry0.2 mm
Repetition accuracy, gripper0.01 mm
Number of gripper jaws2
Drive systemElectrical
Mounting positionAny
Gripper functionParallel
DesignWorm gear unit, T-shape, Rack and pinion, Electric gripper
Conforms to standardIEC 61010-1
GuidePlain-bearing guide
Position detectionVia proximity switch
Type of motorDC servo motor
Operator controlsLatching switch
Ready status indicationLED
Max. cycle frequency0.7 Hz
Max. mass per external gripper finger150 g
Max. current consumption2000 mA
Nominal operating voltage DC24 V
Permissible voltage fluctuations±10%
ApprovalRCM
KC markKC-EMV
CE mark (see declaration of conformity)To EU EMC Directive, In accordance with EU RoHS Directive
UKCA marking (see declaration of conformity)To UK RoHS instructions
Corrosion resistance class CRC1 - Low corrosion stress
LABS (PWIS) conformityVDMA24364-B2-L
Suitability for the production of Li-ion batteriesCopper content max. 5 % by mass (except PCBs, cables, connectors and coils)
Sound pressure level70 dB(A)
Degree of protectionIP40
Ambient temperature5 to 60 °C
Total gripping force218 N
Mass moment of inertia2.02 kgcm²
Max. force on gripper jaw Fz static325 N
Max. torque at gripper Mx static13 Nm
Max. torque at gripper My static8 Nm
Max. torque at gripper Mz static13 Nm
Lubrication interval for guide components2 million cycles
Product weight532 g
Electrical connection5-pin, Cable with plug, M12x1
Type of mountingVia female thread and centring sleeve, Via through-hole and centring sleeve
Note on materialsRoHS compliant
Housing materialAnodised aluminium
Gripper jaw materialHigh-alloy stainless steel
Weight0.75 kg
ManufacturerFesto
Hersteller-NrEHPS-20-A
EAN4052568445751
Zolltarifnummer84798997
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
MaterialAluminium
Actuation typeElectrical
Operating voltage24 V DC
Protection ratingIP40
Temperaturbereich5-60 °C
Temperature (max.)60
