Toothed belt axis size 80 stroke 300 mm EGC-80-300-TB-KF-0H-GK - Festo 556814
With 300 mm of working stroke and up to 5 m/s, the toothed belt axis EGC-80-300-TB-KF-0H-GK moves loads quickly in size 80. 350 N of feed force and ±0.08 mm repetition accuracy make the movement strong and repeatable. The toothed belt drive converts each motor revolution into 90 mm of feed.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
300 mm of working stroke, up to 5 m/s and ±0.08 mm repetition accuracy: these are the key values of the Festo toothed belt axis EGC-80-300-TB-KF-0H-GK in size 80.
Why this axis
- Up to 5 m/s travel speed and 50 m/s² acceleration for short cycle times
- Repetition accuracy of ±0.08 mm for reproducible positions
- Feed force up to 350 N
- Recirculating ball bearing guide for a precisely guided slide movement over 300 mm
- Feed constant of 90 mm/rev, toothed belt pitch 3 mm
- Degree of protection IP40 for -10 to 60 °C ambient temperature
Applications
Fields of use are handling, packaging and assembly, wherever 300 mm of travel must be covered quickly. The EGC-80-300-TB-KF-0H-GK is designed for stepper and servo motors. Any mounting position is possible.
Technical data
| Type | EGC-80-300-TB-KF-0H-GK |
|---|---|
| Festo part number | 556814 |
| Working stroke | 300 mm |
| Effective diameter of drive pinion | 28.65 mm |
| Size | 80 |
| Toothed-belt pitch | 3 mm |
| Mounting position | Any |
| Guide | Recirculating ball bearing guide |
| Design | With toothed belt |
| Type of motor | Stepper motor, Servo motor |
| Functional principle of measuring system | Incremental |
| Maximum acceleration | 50 m/s² |
| Maximum speed | 5 m/s |
| Repetition accuracy | ±0.08 mm |
| Duty cycle | 100% |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Degree of protection | IP40 |
| Ambient temperature | -10 to 60 °C |
| 2nd moment of area Iy | 844000 mm⁴ |
| Maximum force Fy | 3050 N |
| Maximum force Fz | 3050 N |
| Maximum force Fy total axis | 3050 N |
| Maximum force Fz total axis | 3050 N |
| Fy at theoretical life value of 100 km (only guide consideration) | 11236 N |
| Fz at theoretical life value of 100 km (only guide consideration) | 11237 N |
| Maximum idle running transfer resistance | 28 N |
| Maximum moment Mx | 36 Nm |
| Maximum moment Mx total axis | 36 Nm |
| Mx at theoretical life value of 100 km (only guide consideration) | 133 Nm |
| Maximum feed force Fx | 350 N |
| Torsional mass moment of inertia It | 551000 mm⁴ |
| Mass moment of inertia JH per metre of stroke | 0.19 kgcm² |
| Mass moment of inertia JL per kg of working load | 2.05 kgcm² |
| Feed constant | 90 mm/U |
| Reference service life | 5000 km |
| Pneumatic connection, clamping unit | M5 |
| Material end cap | Anodised wrought aluminium alloy |
| Material profile | Anodised wrought aluminium alloy |
| Note on materials | RoHS compliant |
| Material drive cover | Anodised wrought aluminium alloy |
| Material guide slide | Steel |
| Material guide rail | Steel |
| Material pulleys | High-alloy stainless steel |
| Material slide | Anodised wrought aluminium alloy |
| Material toothed belt clamping piece | Cast stainless steel |
| Material toothed belt | Polyurethane with steel cord and nylon cover, Polychloroprene or nitrile rubber (NBR) with glass cord and nylon coating |
| Weight | 5 kg |
| Manufacturer | Festo |
| Hersteller-Nr | EGC-80- -TB-KF |
| Zolltarifnummer | 84799070 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Stroke [mm] | 300 |
| Housing material | Aluminium, anodised |
| Series | EGC |
| Protection rating | IP40 |
| Temperaturbereich | -10-60 °C |
| Temperature (max.) | 60 |
