Ball screw axis size 80 stroke 450 mm pitch 20 mm EGC-80-450-BS-20P-KF-0H-MR-GK - Festo 588694

Festo ✓ Original product Brand new

The Festo ball screw axis EGC-80-450-BS-20P-KF-0H-MR-GK offers a working stroke of 450 mm in size 80. The ball screw with a 20 mm pitch turns every motor revolution into 20 mm of feed. Festo part number 588694.

Net
€1,971.65
excl. VAT
Item FES-588694
Manufacturer no. EGC-80-450-BS-20P-KF-0H-MR-GK
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Festo ball screw axis EGC-80-450-BS-20P-KF-0H-MR-GK offers a working stroke of 450 mm in size 80. It is driven by a ball screw with a 20 mm pitch.

Why this axis

  • Recirculating ball bearing guide for a precisely guided slide movement over 450 mm
  • Spindle pitch of 20 mm/rev for a defined feed per revolution

Applications

For assembly, lab automation and test engineering, where 450 mm of stroke is approached with a defined force.

Technical data

TypeEGC-80-450-BS-20P-KF-0H-MR-GK
Festo part number588694
Product typeBall screw axis
SeriesEGC
Size80
Working stroke450 mm
DriveBall screw
Spindle pitch20 mm/rev
GuideRecirculating ball bearing guide
ManufacturerFesto
Hersteller-NrEGC-80-450-BS-20P-KF-0H-MR-GK
Zolltarifnummer90330090
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
Stroke [mm]450
DesignElectro-mechanical linear axis, With Ball screw
