Toothed belt axis size 50 stroke 150 mm EGC-50-150-TB-KF-0H-GK - Festo 556812
Up to 3 m/s travel speed and 50 m/s² acceleration: the Festo toothed belt axis EGC-50-150-TB-KF-0H-GK covers a working stroke of 150 mm in size 50. 50 N of feed force and ±0.08 mm repetition accuracy make the movement strong and repeatable. Weight 0.85 kg. Festo part number 556812.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
150 mm of working stroke, up to 3 m/s and ±0.08 mm repetition accuracy: these are the key values of the Festo toothed belt axis EGC-50-150-TB-KF-0H-GK in size 50.
Benefits
- Up to 3 m/s travel speed and 50 m/s² acceleration for short cycle times
- Repetition accuracy of ±0.08 mm for reproducible positions
- Feed force up to 50 N
- Recirculating ball bearing guide for transverse forces up to 650 N (Fy) and 650 N (Fz) and moments up to 10 Nm (My)
- Feed constant of 58 mm/rev, toothed belt pitch 2 mm
- Degree of protection IP40 for -10 to 60 °C ambient temperature
Applications
The toothed belt shows its strengths on long, fast moves, here over 150 mm in size 50. The EGC-50-150-TB-KF-0H-GK is designed for stepper and servo motors. Any mounting position is possible.
Technical data
| Type | EGC-50-150-TB-KF-0H-GK |
|---|---|
| Festo part number | 556812 |
| Working stroke | 150 mm |
| Effective diameter of drive pinion | 18.46 mm |
| Size | 50 |
| Toothed-belt pitch | 2 mm |
| Mounting position | Any |
| Guide | Recirculating ball bearing guide |
| Design | With toothed belt |
| Type of motor | Stepper motor, Servo motor |
| Maximum acceleration | 50 m/s² |
| Maximum speed | 3 m/s |
| Repetition accuracy | ±0.08 mm |
| Duty cycle | 100% |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Degree of protection | IP40 |
| Ambient temperature | -10 to 60 °C |
| 2nd moment of area Iy | 84000 mm⁴ |
| 2nd moment of area Iz | 114000 mm⁴ |
| Maximum force Fy | 650 N |
| Maximum force Fz | 650 N |
| Maximum force Fy total axis | 650 N |
| Maximum force Fz total axis | 650 N |
| Fy at theoretical life value of 100 km (only guide consideration) | 2395 N |
| Fz at theoretical life value of 100 km (only guide consideration) | 2395 N |
| Maximum idle running transfer resistance | 8 N |
| Maximum moment Mx | 3.5 Nm |
| Maximum moment My | 10 Nm |
| Maximum moment Mz | 10 Nm |
| Maximum moment Mx total axis | 3.5 Nm |
| Maximum moment My total axis | 10 Nm |
| Maximum moment Mz total axis | 10 Nm |
| Mx at theoretical life value of 100 km (only guide consideration) | 13 Nm |
| My at theoretical life value of 100 km (only guide consideration) | 37 Nm |
| Mz at theoretical life value of 100 km (only guide consideration) | 37 Nm |
| Maximum feed force Fx | 50 N |
| Torsional mass moment of inertia It | 42500 mm⁴ |
| Mass moment of inertia JH per metre of stroke | 0.026 kgcm² |
| Mass moment of inertia JL per kg of working load | 0.85 kgcm² |
| Feed constant | 58 mm/U |
| Reference service life | 5000 km |
| Material end cap | Wrought aluminium alloy, anodised |
| Material profile | Wrought aluminium alloy, anodised |
| Note on materials | RoHS compliant |
| Material drive cover | Wrought aluminium alloy, anodised |
| Material guide slide | Steel |
| Material guide rail | Steel |
| Material pulleys | High-alloy stainless steel |
| Material slide | Wrought aluminium alloy, anodised |
| Material toothed belt clamping piece | nickel-plated |
| Material toothed belt | Polychloroprene or nitrile rubber (NBR) with glass cord and nylon coating |
| Weight | 0.85 kg |
| Manufacturer | Festo |
| Hersteller-Nr | EGC-50- -TB-KF |
| Zolltarifnummer | 84799070 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Stroke [mm] | 150 |
| Housing material | Aluminium, anodised |
| Series | EGC |
| Protection rating | IP40 |
| Temperaturbereich | -10-60 °C |
| Temperature (max.) | 60 |
