Stainless steel screw coupling, coupler size 6, G 1"(female thread)
This item joins two hydraulic lines into a connection that can be released and is listed as a stainless steel screw coupling. The defining values are female thread G 1" and PN 250 bar.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
Listed as a stainless steel screw coupling, this version joins two hydraulic lines into a connection that can be released. Decisive here are female thread G 1" and PN 250 bar. The version is made of 1.4404.
Benefits
- A (coupler thread) M 48x3
- dimension B 55 mm
- temperature range -20 to +150 °C
- size and nominal width from the data sheet for matching coupler and plug, verified by female thread G 1"
- material 1.4404 as stated in the data
- PN 250 bar
Applications
This design is used for hydraulic lines on machines, plant and commercial vehicles, here with female thread G 1".
Technical data
| version | coupler |
|---|---|
| female thread | G 1" |
| A (coupler thread) | M 48x3 |
| dimension B [mm] | 55 |
| DN (ISO) [mm] | 25 |
| size | 6 |
| PN [bar] | 250 |
| Weight | 0.750000 |
| Manufacturer | Fluidics equipment |
| Hersteller-Nr | 512527.6 ES |
| EAN | 4050571718107 |
| Zolltarifnummer | 84812010 |
| GPSR Herstellerdaten | A1-ESD equipment GmbH. Keldersstr. 15, DE-42697 Solingen, www.esd.equipment |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Ausführung | Muffe |
| Gewinde innen | G 1" |
