Parallel kit motor interface 80 PB/R, 3 Nm EAMM-U-87-T46-80PB-114 - Festo 8096289

Festo ✓ Original product Brand new

The parallel kit EAMM-U-87-T46-80PB-114 from Festo places the motor parallel to the actuator and so shortens the overall length of the unit. Transmits up to 3 Nm of torque between motor and drive, plus fits actuators with code T46 and motors with code 80 PB, 80R. Genuine Festo accessory.

Net
€276.21
excl. VAT
Item FES-8096289
Manufacturer no. EAMM-U-87-T46-80PB-114
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The parallel kit EAMM-U-87-T46-80PB-114 places the motor parallel to the actuator and so shortens the overall length of the unit. Decisive for selection: motor interface 80 PB/R, 3 Nm, actuator T46.

Benefits

  • Transmits up to 3 Nm of torque between motor and drive
  • Fits actuators with code T46 and motors with code 80 PB, 80R
  • Ratio 1:1 at a shaft centre distance of 114 mm
  • Speeds up to 3000 1/min permitted
  • 44.4 kgmm² mass moment of inertia, ready for the drive calculation
  • Frictional torque of 0.22 Nm for the torque budget

Application

Before ordering, check that the motor carries interface code 80 PB, 80R and the actuator matches T46. Useful where axial space is limited, as with the EAMM-U-87-T46-80PB-114 in size 87. The mounting position of EAMM-U-87-T46-80PB-114 is freely selectable, ambient temperature range 0 to 50 °C.

Technical data

FeatureValue
TypeEAMM-U-87-T46-80PB-114
Festo part number8096289
Size87
Centre-to-centre distance114 mm
Mounting positionany
Gear ratio1:1
Max. rotational speed3000 1/min
LABS (PWIS) conformityVDMA24364 zone III
Storage temperature-20 to 60 °C
Relative air humidity0 to 95 %
Degree of protectionIP40
Ambient temperature0 to 50 °C
Mass moment of inertia44.4 kgmm²
Frictional torque independent of load0.22 Nm
Transmittable torque3 Nm
Product weight1062 g
Interface code, actuatorT46
Interface code, motor in80 PB, 80R
Note on materialsRoHS compliant
ManufacturerFesto
Hersteller-NrEAMM-U-87-T46-80PB-114
EAN4052568299309
Zolltarifnummer84839089
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
SeriesEAMM
Protection ratingIP40
Temperaturbereich0-50 °C
Temperature (max.)50
