Parallel kit motor interface 80 P/PA/RA, 3 Nm EAMM-U-87-T46-80P-114 - Festo 4822696
The Festo parallel kit EAMM-U-87-T46-80P-114 places the motor parallel to the actuator and so shortens the overall length of the unit. Transmittable torque of 3 Nm for sizing the drive train, plus fits actuators with code T46 and motors with code 80 P, 80PA, 80RA. Genuine Festo accessory.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The parallel kit EAMM-U-87-T46-80P-114 places the motor parallel to the actuator and so shortens the overall length of the unit. At a glance: motor interface 80 P/PA/RA, 3 Nm, actuator T46.
Benefits
- Transmittable torque of 3 Nm for sizing the drive train
- Fits actuators with code T46 and motors with code 80 P, 80PA, 80RA
- Ratio 1:1 at a shaft centre distance of 114 mm
- Speeds up to 3000 1/min permitted
- 44.4 kgmm² mass moment of inertia, ready for the drive calculation
- Frictional torque of 0.22 Nm for the torque budget
Application
Before ordering, check that the motor carries interface code 80 P, 80PA, 80RA and the actuator matches T46. Useful where axial space is limited, as with the EAMM-U-87-T46-80P-114 in size 87. The mounting position of EAMM-U-87-T46-80P-114 is freely selectable, ambient temperature range 0 to 50 °C.
Technical data
| Feature | Value |
|---|---|
| Type | EAMM-U-87-T46-80P-114 |
| Festo part number | 4822696 |
| Size | 87 |
| Centre-to-centre distance | 114 mm |
| Mounting position | any |
| Gear ratio | 1:1 |
| Max. rotational speed | 3000 1/min |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Storage temperature | -20 to 60 °C |
| Relative air humidity | 0 to 95 % |
| Degree of protection | IP40 |
| Ambient temperature | 0 to 50 °C |
| Mass moment of inertia | 44.4 kgmm² |
| Frictional torque independent of load | 0.22 Nm |
| Transmittable torque | 3 Nm |
| Product weight | 1140 g |
| Interface code, actuator | T46 |
| Interface code, motor in | 80 P, 80PA, 80RA |
| Note on materials | RoHS compliant |
| Weight | 1.1 kg |
| Manufacturer | Festo |
| Hersteller-Nr | EAMM-U-87-T46-80P-114 |
| EAN | 4052568292065 |
| Zolltarifnummer | 84839089 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Series | EAMM |
| Protection rating | IP40 |
| Temperaturbereich | 0-50 °C |
| Temperature (max.) | 50 |
