Parallel kit size 86 for motor mounting, actuator D50, motor 80PB or 80R, 9.5 Nm EAMM-U-86-D50-80PB-102 - Festo 8107089

Festo ✓ Original product Brand new

The parallel kit EAMM-U-86-D50-80PB-102 places a motor with interface 80PB or 80R parallel to the drive with code D50, keeping the overall length short. It transmits up to 9.5 Nm. Speed up to 5000 1/min, degree of protection IP40. Mass moment of inertia 175 kgmm².

Net
€690.53
excl. VAT
Item FES-8107089
Manufacturer no. EAMM-U-86-D50-80PB-102
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The Festo parallel kit EAMM-U-86-D50-80PB-102 mounts the motor (interface 80PB or 80R) parallel to the drive (interface D50). It transmits up to 9.5 Nm.

Benefits

  • Transmittable torque 9.5 Nm between motor and drive
  • Speed up to 5000 1/min
  • Mass moment of inertia 175 kgmm² as input for drive sizing
  • No-load driving torque 0.25 Nm
  • Interfaces actuator D50, motor 80PB or 80R
  • Degree of protection IP40, ambient temperature -10 to 60 °C

Applications

The EAMM-U-86-D50-80PB-102 is used whenever a motor with interface code 80PB or 80R has to be fitted to an electric drive with interface D50. Typical applications are positioning axes in assembly, packaging and laboratory automation.

Technical data

Size86
Mounting positionAny
Max. rotational speed5000 1/min
LABS (PWIS) conformityVDMA24364-B2-L
Storage temperature-25 to 60 °C
Relative air humidity0 - 95%
Degree of protectionIP40
Ambient temperature-10 to 60 °C
Mass moment of inertia175 kgmm²
Frictional torque independent of load0.25 Nm
Transmittable torque9.5 Nm
Product weight2500 g
Interface code, actuatorD50
Interface code, motor in80PB, 80R
Note on materialsRoHS compliant
Weight2.4 kg
ManufacturerFesto
Hersteller-NrEAMM-U-86-D50-80PB-102
EAN4052568551964
Zolltarifnummer84839089
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
SeriesEAMM
Protection ratingIP40
Temperaturbereich-10-60 °C
Temperature (max.)60
