Parallel kit for motor mounting, 3 Nm, actuator T42, motor 57A EAMM-U-65-T42-57A-114 - Festo 8222166
With the parallel kit EAMM-U-65-T42-57A-114 the motor sits alongside the axis instead of extending it. Up to 3 Nm of torque is transmitted, the part is rated for up to 3000 1/min. Matches actuator interface T42 and motor interface 57A.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
With the parallel kit EAMM-U-65-T42-57A-114 the motor sits alongside the axis instead of extending it. Up to 3 Nm of torque is transmitted, the part is rated for up to 3000 1/min.
Key benefits
- Transmittable torque 3 Nm
- Speeds up to 3000 1/min
- Ratio 1:1, motor speed and torque reach the axis unchanged
- No-load driving torque only 0.22 Nm
- Mass moment of inertia 41.2 kgmm² for sizing the drive
- Degree of protection IP40, protected against solid objects from 1 mm
Application
For mounting a motor to Festo electric axes. Before ordering, compare the interface codes of axis and motor with the table, so EAMM-U-65-T42-57A-114 fits without rework.
Technical data
| Type | EAMM-U-65-T42-57A-114 |
|---|---|
| Festo part no. | 8222166 |
| Size | 65 |
| Centre-to-centre distance | 114 mm |
| Gear unit ratio | 1:1 |
| Transmittable torque | 3 Nm |
| Frictional torque independent of load | 0.22 Nm |
| Max. rotational speed | 3000 1/min |
| Mass moment of inertia | 41.2 kgmm² |
| Interface code, actuator | T42 |
| Interface code, motor in | 57A |
| Degree of protection | IP40 |
| Mounting position | Any |
| Ambient temperature | 0 to 50 °C |
| Storage temperature | -20 to 60 °C |
| Relative air humidity | 0 - 95 % |
| LABS (PWIS) conformity | VDMA 24364-zone III |
| Product weight | 667 g |
| Note on materials | RoHS compliant |
| Weight | 0.7 kg |
| Manufacturer | Festo |
| Hersteller-Nr | EAMM-U-65-T42-57A-114 |
| EAN | 4052568801779 |
| Zolltarifnummer | 84839089 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Series | EAMM |
| Protection rating | IP40 |
| Temperaturbereich | 0-50 °C |
| Temperature (max.) | 50 |
