Parallel kit motor interface 40RA, 0.5 Nm EAMM-U-45-V25-40RA-63 - Festo 8095513

Festo ✓ Original product Brand new

The parallel kit EAMM-U-45-V25-40RA-63 from Festo places the motor parallel to the actuator and so shortens the overall length of the unit. Transmittable torque of 0.5 Nm for sizing the drive train, plus clear matching via interface codes V25 (actuator) and 40RA (motor). Genuine Festo accessory.

Net
€179.54
excl. VAT
Item FES-8095513
Manufacturer no. EAMM-U-45-V25-40RA-63
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The parallel kit EAMM-U-45-V25-40RA-63 places the motor parallel to the actuator and so shortens the overall length of the unit. Decisive for selection: motor interface 40RA, 0.5 Nm, actuator V25.

Benefits

  • Transmittable torque of 0.5 Nm for sizing the drive train
  • Clear matching via interface codes V25 (actuator) and 40RA (motor)
  • Ratio 1:1 at a shaft centre distance of 63 mm
  • Maximum rotational speed of 3600 1/min
  • 4.35 kgmm² mass moment of inertia, ready for the drive calculation
  • Frictional torque of 0.05 Nm for the torque budget

Application

Before ordering, check that the motor carries interface code 40RA and the actuator matches V25. Useful where axial space is limited, as with the EAMM-U-45-V25-40RA-63 in size 45. EAMM-U-45-V25-40RA-63 can be installed in any mounting position at ambient temperatures of 0 to 50 °C.

Technical data

FeatureValue
TypeEAMM-U-45-V25-40RA-63
Festo part number8095513
Size45
Centre-to-centre distance63 mm
Mounting positionany
Gear ratio1:1
Max. rotational speed3600 1/min
LABS (PWIS) conformityVDMA24364 zone III
Storage temperature-20 to 60 °C
Relative air humidity0 to 95 %
Degree of protectionIP40
Ambient temperature0 to 50 °C
Mass moment of inertia4.35 kgmm²
Frictional torque independent of load0.05 Nm
Transmittable torque0.5 Nm
Product weight245 g
Interface code, actuatorV25
Interface code, motor in40RA
Note on materialsRoHS compliant
Weight0.28 kg
ManufacturerFesto
Hersteller-NrEAMM-U-45-V25-40RA-63
EAN4052568299217
Zolltarifnummer84839089
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
SeriesEAMM
Protection ratingIP40
Temperaturbereich0-50 °C
Temperature (max.)50
