Parallel kit motor interface 38AA, 0.5 Nm EAMM-U-45-V25-38AA-63 - Festo 8093197
The Festo parallel kit EAMM-U-45-V25-38AA-63 places the motor parallel to the actuator and so shortens the overall length of the unit. Transmittable torque of 0.5 Nm for sizing the drive train, plus fits actuators with code V25 and motors with code 38AA. Genuine Festo accessory.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The parallel kit EAMM-U-45-V25-38AA-63 places the motor parallel to the actuator and so shortens the overall length of the unit. The key values: motor interface 38AA, 0.5 Nm, actuator V25.
Benefits
- Transmittable torque of 0.5 Nm for sizing the drive train
- Fits actuators with code V25 and motors with code 38AA
- Ratio 1:1 at a shaft centre distance of 63 mm
- Maximum rotational speed of 3600 1/min
- Mass moment of inertia of 4.35 kgmm² for motor sizing
- Frictional torque of 0.05 Nm for the torque budget
Application
Before ordering, check that the motor carries interface code 38AA and the actuator matches V25. Useful where axial space is limited, as with the EAMM-U-45-V25-38AA-63 in size 45. The mounting position of EAMM-U-45-V25-38AA-63 is freely selectable, ambient temperature range 0 to 50 °C.
Technical data
| Feature | Value |
|---|---|
| Type | EAMM-U-45-V25-38AA-63 |
| Festo part number | 8093197 |
| Size | 45 |
| Centre-to-centre distance | 63 mm |
| Mounting position | any |
| Gear ratio | 1:1 |
| Max. rotational speed | 3600 1/min |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Storage temperature | -20 to 60 °C |
| Relative air humidity | 0 to 95 % |
| Degree of protection | IP40 |
| Ambient temperature | 0 to 50 °C |
| Mass moment of inertia | 4.35 kgmm² |
| Frictional torque independent of load | 0.05 Nm |
| Transmittable torque | 0.5 Nm |
| Product weight | 264 g |
| Interface code, actuator | V25 |
| Interface code, motor in | 38AA |
| Note on materials | RoHS compliant |
| Manufacturer | Festo |
| Hersteller-Nr | EAMM-U-45-V25-38AA-63 |
| EAN | 4052568299095 |
| Zolltarifnummer | 84839089 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Series | EAMM |
| Protection rating | IP40 |
| Temperaturbereich | 0-50 °C |
| Temperature (max.) | 50 |
