Parallel kit motor interface 90R, 25 Nm EAMM-U-110-D60-90R-120 - Festo 1202981
The Festo parallel kit EAMM-U-110-D60-90R-120 places the motor parallel to the actuator and so shortens the overall length of the unit. Transmittable torque of 25 Nm for sizing the drive train, plus clear matching via interface codes D60B (actuator) and 90R (motor). Genuine Festo accessory.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The parallel kit EAMM-U-110-D60-90R-120 places the motor parallel to the actuator and so shortens the overall length of the unit. Decisive for selection: motor interface 90R, 25 Nm, actuator D60B.
Benefits
- Transmittable torque of 25 Nm for sizing the drive train
- Clear matching via interface codes D60B (actuator) and 90R (motor)
- Ratio 1:1, motor speed is passed on unchanged
- Speeds up to 5000 1/min permitted
- 799 kgmm² mass moment of inertia, ready for the drive calculation
- Frictional torque of 0.3 Nm for the torque budget
Application
Before ordering, check that the motor carries interface code 90R and the actuator matches D60B. The parallel layout of the EAMM-U-110-D60-90R-120 suits installations with little space behind the actuator. The mounting position of EAMM-U-110-D60-90R-120 is freely selectable, ambient temperature range -10 to 60 °C.
Technical data
| Feature | Value |
|---|---|
| Type | EAMM-U-110-D60-90R-120 |
| Festo part number | 1202981 |
| Size | 110 |
| Mounting position | any |
| Gear ratio | 1:1 |
| Max. rotational speed | 5000 1/min |
| LABS (PWIS) conformity | VDMA24364 zone III |
| Storage temperature | -25 to 60 °C |
| Relative air humidity | 0 to 95 % |
| Degree of protection | IP40 |
| Ambient temperature | -10 to 60 °C |
| Mass moment of inertia | 799 kgmm² |
| Frictional torque independent of load | 0.3 Nm |
| Transmittable torque | 25 Nm |
| Product weight | 5070 g |
| Interface code, actuator | D60B |
| Interface code, motor in | 90R |
| Note on materials | RoHS compliant |
| Weight | 5 kg |
| Manufacturer | Festo |
| Hersteller-Nr | EAMM-U-110-D60-90R-120 |
| EAN | 4052568414016 |
| Zolltarifnummer | 84839089 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Series | EAMM |
| Protection rating | IP40 |
| Temperaturbereich | -10-60 °C |
| Temperature (max.) | 60 |
