Axial kit motor interface 57A, 1.5 Nm EAMM-A-V32-57A - Festo 4597016
The Festo axial kit EAMM-A-V32-57A connects the motor axially, in line with the drive axis, to the actuator. Transmits up to 1.5 Nm of torque between motor and drive, plus clear matching via interface codes V32 (actuator) and 57A (motor). Speeds up to 10000 1/min permitted. Genuine Festo accessory.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The axial kit EAMM-A-V32-57A connects the motor axially, in line with the drive axis, to the actuator. At a glance: motor interface 57A, 1.5 Nm, actuator V32.
Benefits
- Transmits up to 1.5 Nm of torque between motor and drive
- Clear matching via interface codes V32 (actuator) and 57A (motor)
- Speeds up to 10000 1/min permitted
- 0.19 kgmm² mass moment of inertia, ready for the drive calculation
- Degree of protection IP40
- Suitable for ambient temperatures of -10 to 60 °C
Application
Before ordering, check that the motor carries interface code 57A and the actuator matches V32. The axial design keeps the EAMM-A-V32-57A unit slim in width. EAMM-A-V32-57A can be installed in any mounting position at ambient temperatures of -10 to 60 °C.
Technical data
| Feature | Value |
|---|---|
| Type | EAMM-A-V32-57A |
| Festo part number | 4597016 |
| Nominal length | 41.5 mm |
| Mounting position | any |
| Max. rotational speed | 10000 1/min |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Storage temperature | -25 to 60 °C |
| Relative air humidity | 0 to 95 % |
| Degree of protection | IP40 |
| Ambient temperature | -10 to 60 °C |
| Mass moment of inertia | 0.19 kgmm² |
| Transmittable torque | 1.5 Nm |
| Product weight | 180 g |
| Interface code, actuator | V32 |
| Interface code, motor in | 57A |
| Note on materials | RoHS compliant |
| Weight | 0.21 kg |
| Manufacturer | Festo |
| Hersteller-Nr | EAMM-A-V32-57A |
| EAN | 4052568291884 |
| Zolltarifnummer | 84836080 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Series | EAMM |
| Protection rating | IP40 |
| Temperaturbereich | -10-60 °C |
| Temperature (max.) | 60 |
