Axial kit motor interface 40P, 0.5 Nm EAMM-A-V25-40P - Festo 4491059
The Festo axial kit EAMM-A-V25-40P connects the motor axially, in line with the drive axis, to the actuator. Transmits up to 0.5 Nm of torque between motor and drive, plus fits actuators with code V25 and motors with code 40P. Maximum rotational speed of 10000 1/min. Genuine Festo accessory.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The axial kit EAMM-A-V25-40P connects the motor axially, in line with the drive axis, to the actuator. At a glance: motor interface 40P, 0.5 Nm, actuator V25.
Benefits
- Transmits up to 0.5 Nm of torque between motor and drive
- Fits actuators with code V25 and motors with code 40P
- Maximum rotational speed of 10000 1/min
- Mass moment of inertia of 0.19 kgmm² for motor sizing
- Degree of protection IP40
- Ambient temperature -10 to 60 °C
Application
Before ordering, check that the motor carries interface code 40P and the actuator matches V25. The axial design keeps the EAMM-A-V25-40P unit slim in width. The mounting position of EAMM-A-V25-40P is freely selectable, ambient temperature range -10 to 60 °C.
Technical data
| Feature | Value |
|---|---|
| Type | EAMM-A-V25-40P |
| Festo part number | 4491059 |
| Nominal length | 41 mm |
| Mounting position | any |
| Max. rotational speed | 10000 1/min |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Storage temperature | -25 to 60 °C |
| Relative air humidity | 0 to 95 % |
| Degree of protection | IP40 |
| Ambient temperature | -10 to 60 °C |
| Mass moment of inertia | 0.19 kgmm² |
| Transmittable torque | 0.5 Nm |
| Product weight | 90 g |
| Interface code, actuator | V25 |
| Interface code, motor in | 40P |
| Note on materials | RoHS compliant |
| Weight | 0.12 kg |
| Manufacturer | Festo |
| Hersteller-Nr | EAMM-A-V25-40P |
| EAN | 4052568291785 |
| Zolltarifnummer | 84836080 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Series | EAMM |
| Protection rating | IP40 |
| Temperaturbereich | -10-60 °C |
| Temperature (max.) | 60 |
