Axial kit motor interface 60 P/PA, 10 Nm EAMM-A-T42-60P - Festo 4133487
The axial kit EAMM-A-T42-60P from Festo connects the motor axially, in line with the drive axis, to the actuator. Transmits up to 10 Nm of torque between motor and drive, plus clear matching via interface codes T42 (actuator) and 60 P, 60PA (motor). Maximum rotational speed of 8000 1/min.
- Specialist dealer since 2009
- Invoice payment for regular customers
- Worldwide shipping
- Technical questions clarified with the manufacturer
Description
The axial kit EAMM-A-T42-60P connects the motor axially, in line with the drive axis, to the actuator. The key values: motor interface 60 P/PA, 10 Nm, actuator T42.
Benefits
- Transmits up to 10 Nm of torque between motor and drive
- Clear matching via interface codes T42 (actuator) and 60 P, 60PA (motor)
- Maximum rotational speed of 8000 1/min
- Mass moment of inertia of 3.2 kgmm² for motor sizing
- Degree of protection IP40
- Suitable for ambient temperatures of -10 to 60 °C
Application
Before ordering, check that the motor carries interface code 60 P, 60PA and the actuator matches T42. The axial design keeps the EAMM-A-T42-60P unit slim in width. The mounting position of EAMM-A-T42-60P is freely selectable, ambient temperature range -10 to 60 °C.
Technical data
| Feature | Value |
|---|---|
| Type | EAMM-A-T42-60P |
| Festo part number | 4133487 |
| Nominal length | 49 mm |
| Mounting position | any |
| Max. rotational speed | 8000 1/min |
| LABS (PWIS) conformity | VDMA24364-B2-L |
| Storage temperature | -25 to 60 °C |
| Relative air humidity | 0 to 95 % |
| Degree of protection | IP40 |
| Ambient temperature | -10 to 60 °C |
| Mass moment of inertia | 3.2 kgmm² |
| Transmittable torque | 10 Nm |
| Product weight | 334 g |
| Interface code, actuator | T42 |
| Interface code, motor in | 60 P, 60PA |
| Note on materials | RoHS compliant |
| Weight | 0.37 kg |
| Manufacturer | Festo |
| Hersteller-Nr | EAMM-A-T42-60P |
| EAN | 4052568291372 |
| Zolltarifnummer | 84836080 |
| GPSR Herstellerdaten | Festo Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Series | EAMM |
| Protection rating | IP40 |
| Temperaturbereich | -10-60 °C |
| Temperature (max.) | 60 |
