Axial kit for motor mounting, actuator L62, motor 140A or 150A, 47 Nm EAMM-A-L62-150A - Festo 8157270

Festo ✓ Original product Brand new

The axial kit EAMM-A-L62-150A mounts a motor with interface 140A or 150A in line with a drive carrying interface code L62. It transmits up to 47 Nm. Speed up to 5500 1/min, degree of protection IP40. Mass moment of inertia 151 kgmm².

Net
€379.48
excl. VAT
Item FES-8157270
Manufacturer no. EAMM-A-L62-150A
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

47 Nm transmittable torque, degree of protection IP40 and matching interfaces for actuator L62 and motor 140A or 150A: with the axial kit EAMM-A-L62-150A motor mounting is done without designing your own adapter.

Benefits

  • Transmittable torque 47 Nm between motor and drive
  • Speed up to 5500 1/min
  • Mass moment of inertia 151 kgmm² as input for drive sizing
  • Interfaces actuator L62, motor 140A or 150A
  • Degree of protection IP40, ambient temperature -10 to 60 °C

Applications

When sizing the axis, the mass moment of inertia of 151 kgmm² and the transmittable torque of 47 Nm feed into the choice of motor and controller. The kit is mounted between motor (140A or 150A) and drive (L62).

Technical data

Nominal length72.5 mm
Mounting positionAny
Max. rotational speed5500 1/min
LABS (PWIS) conformityVDMA24364-B2-L
Storage temperature-25 to 60 °C
Relative air humidity0 - 95%
Degree of protectionIP40
Ambient temperature-10 to 60 °C
Mass moment of inertia151 kgmm²
Transmittable torque47 Nm
Product weight2526 g
Interface code, actuatorL62
Interface code, motor in140A, 150A
Note on materialsRoHS compliant
ManufacturerFesto
Hersteller-NrEAMM-A-L62-150A
EAN4052568596934
Zolltarifnummer84836080
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
SeriesEAMM
Protection ratingIP40
Temperaturbereich-10-60 °C
Temperature (max.)60
