Coupling Ø 11 / 16 mm, 16 Nm EAMD-32-32-11-16X20-U - Festo 8086050

Festo ✓ Original product Brand new

The coupling EAMD-32-32-11-16X20-U from Festo transmits the torque between motor shaft and drive shaft. Transmits up to 16 Nm of torque between motor and drive, plus mounting diameters of 11 mm and 16 mm for the two shafts. Speeds up to 8000 1/min permitted. Genuine Festo accessory.

Net
€81.13
excl. VAT
Item FES-8086050
Manufacturer no. EAMD-32-32-11-16X20-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

The coupling EAMD-32-32-11-16X20-U transmits the torque between motor shaft and drive shaft. Decisive for selection: Ø 11 / 16 mm, 16 Nm, size 32.

Benefits

  • Transmits up to 16 Nm of torque between motor and drive
  • Mounting diameters of 11 mm and 16 mm for the two shafts
  • Speeds up to 8000 1/min permitted
  • 14.5 kgmm² mass moment of inertia, ready for the drive calculation
  • Nominal length of 32 mm
  • Ambient temperature -25 to 60 °C

Application

The shaft diameters of motor and drive must match the mounting bores of the EAMD-32-32-11-16X20-U. EAMD-32-32-11-16X20-U can be installed in any mounting position at ambient temperatures of -25 to 60 °C.

Technical data

FeatureValue
TypeEAMD-32-32-11-16X20-U
Festo part number8086050
Mounting diameter 111 mm
Mounting diameter 216 mm
Size32
Nominal length32 mm
Mounting positionany
Max. rotational speed8000 1/min
LABS (PWIS) conformityVDMA24364-B2-L
Storage temperature-25 to 60 °C
Relative air humidity0 to 95 %
Ambient temperature-25 to 60 °C
Mass moment of inertia14.5 kgmm²
Transmittable torque16 Nm
Product weight126 g
Note on materialsRoHS compliant
Weight0.125 kg
ManufacturerFesto
Hersteller-NrEAMD-32-32-11-16X20-U
EAN4052568452957
Zolltarifnummer84836080
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
SeriesEAMD
Temperature (max.)60
