Coupling for motor mounting Ø 14/16 mm, 21 Nm EAMC-42-50-14-16-U - Festo 8228280

Festo ✓ Original product Brand new

As the link between two shafts, the coupling EAMC-42-50-14-16-U transmits the motor torque. The mounting diameters are 14 mm and 16 mm. The transmittable torque is 21 Nm, the maximum speed is 6000 1/min.

Net
€64.52
excl. VAT
Item FES-8228280
Manufacturer no. EAMC-42-50-14-16-U
Question about this item
  • Specialist dealer since 2009
  • Invoice payment for regular customers
  • Worldwide shipping
  • Technical questions clarified with the manufacturer

Description

As the link between two shafts, the coupling EAMC-42-50-14-16-U transmits the motor torque. The transmittable torque is 21 Nm, the maximum speed is 6000 1/min.

Why this part

  • Transmittable torque 21 Nm
  • Speeds up to 6000 1/min
  • Mass moment of inertia 34.8 kgmm² for sizing the drive
  • LABS (PWIS) conform to VDMA 24364-B2-L, for paint-sensitive areas
  • Ambient temperature -25 to 60 °C
  • Any mounting position

Application

EAMC-42-50-14-16-U is fitted when mounting motors to Festo electric axes, in new designs or as a replacement. The Festo data for EAMC-42-50-14-16-U in the table are decisive for selection.

Technical data

TypeEAMC-42-50-14-16-U
Festo part no.8228280
Size42
Nominal length50 mm
Mounting diameter 114 mm
Mounting diameter 216 mm
Transmittable torque21 Nm
Max. rotational speed6000 1/min
Mass moment of inertia34.8 kgmm²
Mounting positionAny
Ambient temperature-25 to 60 °C
Storage temperature-25 to 60 °C
Relative air humidity0 - 95 %
LABS (PWIS) conformityVDMA 24364-B2-L
Product weight147 g
Note on materialsRoHS compliant
Weight0.145 kg
ManufacturerFesto
Hersteller-NrEAMC-42-50-14-16-U
EAN4052568773816
Zolltarifnummer84836080
GPSR HerstellerdatenFesto Vertrieb GmbH&Co. KG, Festo Campus 1, DE-73734 Esslingen, festo.com
ArtikelzustandNew
Artikel-AuthentizitätOriginal product
SeriesEAMC
Bore (mm)14
Temperature (max.)60
