Shock absorber, self-adjusting, size 2, stroke 4 mm, 0.1 J per stroke DYSS-2-4-Y1F-F1A - Festo 8119993

Where slides, grippers or workpiece carriers would otherwise run unbraked into the end position, the DYSS-2-4-Y1F-F1A converts up to 0.1 J per stroke into heat. The self-adjusting cushioning of the DYSS-2-4-Y1F-F1A adapts to changing masses and speeds without readjustment.

Benefits

• Energy absorption up to 0.1 J per stroke and 270 J per hour
• Impact speed up to 0.5 m/s, mass range up to 0.8 kg
• Stop force up to 60 N, residual energy max. 0.003 J
• Return time 0.5 s, return force 0.4 N
• Mounting with lock nut, tightening torque max. 0.5 Nm
• Suitable for battery production with reduced Cu/Zn/Ni content (F1a), CRC 2

Applications

Typical locations are end positions of slides, cylinders and handling axes as well as stops in conveyor systems. The DYSS-2-4-Y1F-F1A is rated for -10 to 70 °C ambient temperature, any mounting position.
