Fits existing fixtures because the dimensions follow ISO 21287. Norgren RA/192100/MU/EX/300/90 has 100 mm piston diameter, 300 mm stroke and port G1/8.
Compact cylinder, double acting, extended piston rod, 100 mm bore, 300 mm stroke, G1/8 - Norgren RA/192100/MU/EX/300/90
NORGREN
Original product
Net price (excl. VAT)
€656.81
Item
NRG-RA/192100/MU/EX/300/90
Manufacturer no.
RA/192100/MU/EX/300/90
Personal expert advice
Brand new
Specialist dealer since 2009
Original product
Worldwide shipping
Product data
Manufacturer no.RA/192100/MU/EX/300/90
Customs tariff number84123100
ConditionNew
Artikel
NRG-RA/192100/MU/EX/300/90
Frequently Bought Together
-
This Item:
€656.81
-
Round Cylinder with Flat End Cap, double-acting - Norgren RT/57225/MF/125
€100.43
-
ISOLine profile cylinder, double acting, 63 mm bore, 1100 mm stroke, G3/8 - Norgren PRA/802063/M/1100/UF/D
€373.47
Total price
Norgren RA/192100/MU/EX/300/90 is a double acting compact cylinder with 100 mm piston diameter, 300 mm stroke and port G1/8.
Benefits
- Piston diameter 100 mm to ISO 21287
- Stroke 300 mm
- Theoretical force 4710 N at 6 bar
- Port G1/8 on both sides
- Operating pressure 1 to 10 bar
- Temperature range -5 to 60 °C
Technical data
| Property | Value |
|---|---|
| Manufacturer part number | Norgren RA/192100/MU/EX/300/90 |
| Series | RA/192000/M/EX |
| Standard | ISO 21287 |
| Operating mode | Double acting |
| Port size | G1/8 |
| Piston diameter | 100 mm |
| Stroke | 300 mm |
| Theoretical force at 6 bar | 4710 N |
| Operating pressure | 1 to 10 bar |
| Medium | Compressed air |
| Temperature range | -5 to 60 °C |
| Cushioning | Buffer cushioning |
| Piston version | Magnetic |
| Cylinder barrel | Anodised aluminium |
| Piston rod material | Stainless steel (martensitic) |
| Piston seal | Nitrile rubber (NBR) |
| Piston rod seal | Polyurethane (PU) |
Applications
Machine building, conveying technology and test benches use the compact cylinder where 300 mm of stroke is required.
Standards and conformity
The dimensions conform to ISO 21287. The piston seal is made of Nitrile rubber (NBR). The permissible temperature range is -5 to 60 °C.
| Manufacturer | Norgren |
|---|---|
| Hersteller-Nr | RA/192100/MU/EX/300/90 |
| Zolltarifnummer | 84123100 |
| GPSR Herstellerdaten | Norgren GmbH, Bruckstraße 93, DE-46519 Alpen, www.norgren.com |
| Artikelzustand | New |
| Artikel-Authentizität | Original product |
| Norm | ISO 21287 |
