Flow monitor, G 1", 3 - 10 l/min, 1.4571, nominal pressure PN 300 bar, protection IP 65

Within the pipe run the flow monitor checks the flow rate directly at the measuring point. The device is screwed in with G 1". The switching range extends over 3 - 10 l/min. The body is made of 1.4571. The nominal pressure PN amounts to 300 bar.

Benefits

• Connection thread G 1" for direct installation in the line
• Nominal pressure PN 300 bar, so the load limit is clearly stated
• Temperature range -20 to +120 °C for use in the workshop and in the plant
• Degree of protection IP 65 against dust and moisture at the installation point
• Version according to DIN 43650
• Switching range 3 - 10 l/min as the leading rating of the device

Applications

Monitoring of pumps and nozzles, dosing lines, cooling water distribution and plant monitoring.

Standards and conformity

The data sheets refer to DIN 43650, EN 175301-803. Further approvals are not documented and are therefore not stated.
