Round cylinder, double-acting, Ø 20 mm, stroke 125 mm DSNU-S-20-125-P-A-MX - Festo 5224645

The Festo round cylinder DSNU-S-20-125-P-A-MX is double-acting with a piston Ø of 20 mm and 125 mm stroke and pushes with 188.5 N at 6 bar. The end positions can be sensed with proximity switches.

Benefits

• Theoretical force at 6 bar: 188.5 N advance, 158.3 N return
• Elastic cushioning rings at both ends (P), permissible impact energy 0.2 J
• Cleanroom-suitable, class 5 to ISO 14644-1
• Cylinder barrel and piston rod in high-alloy stainless steel
• Prepared for proximity switches to sense the end positions
• Air connection G1/8, piston rod thread M8

Applications

With 125 mm stroke the DSNU-S-20-125-P-A-MX handles pushing, lifting, clamping and ejecting tasks in assembly, packaging and handling. It is mounted with separate accessories. The M8 piston rod thread on the DSNU-S-20-125-P-A-MX takes the matching rod-end accessories.
